Product Description
Onset HOBOnet Repeater - RXW-RPTR-900
Overview
The HOBOnet Wireless Repeater is designed to work with the HOBOnet Wireless Sensor Network. The repeater is ideal when there is an obstruction between wireless sensors and the RX3000 station or for extending the transmission range of wireless sensors in the network.
900 MHz wireless mesh self-healing technology 450 to 600 meter (1,500 to 2,000 feet) wireless range and up to five hops Up to 50 wireless sensors per RX3000 - Sinmple button-push to join the HOBOnet wireless network
- Onboard memory to ensure no data loss
Powered by rechargeable AA batteries and built-in solar panel
This communication operates in an outdoor environment.
| Operating Temperature Range | -25° to 60°C (-13° to 140°F) with rechargeable batteries |
| Radio Power | 12.6 mW (+11 dBm) non-adjustable |
| Transmission Range | Reliable connection to 457.2 m (1,500 ft) line of sight at 1.8 m (6 ft) high |
| Wireless Data Standard | IEEE 802.15.4 |
| Radio Operating Frequencies | RXMOD-RXW-900: 904924 MHz |
| Modulation Employed | OQPSK (Offset Quadrature Phase Shift Keying) |
| Data Rate | Up to 250 kbps, non-adjustable |
| Duty Cycle | <1% |
| Maximum Number of Motes | 50 motes per one RX Wireless Sensor Network |
| Power Source | Powered by the RX3000 station |
| Dimensions | Mote: 16.2 x 8.59 x 4.14 cm (6.38 x 3.38 x 1.63 inches) |
| Weight | Mote: 159 g (5.62 oz) |
| Materials | Mote: PCPBT, silicone rubber seal |
| Environmental Rating | Mote: IP67, NEMA 6 |
| Compliance Marks |
|
RXMOD-RXW-900
RXMOD-RXW-868
RXMOD-RXW-922
